Powering up python

Jack Atkinson

Senior Research Software Engineer
ICCS - University of Cambridge

2024-01-23

Precursors

Slides and Materials

To access links or follow on your own device these slides can be found at:
https://jackatkinson.net/slides

All materials are available at:

Licensing

Except where otherwise noted, these presentation materials are licensed under the Creative Commons Attribution-NonCommercial 4.0 International (CC BY-NC 4.0) License.

Vectors and icons by SVG Repo used under CC0(1.0)

Precursors

Be nice (Python code of conduct)
Ask questions whenever they arise.
- Someone else is probably wondering the same thing.
I will make mistakes.
- Not all of them will be intentional.

Image from The Shawshank Redemption © Columbia Pictures under fair use.

whoami

Research background in fluid mechanics and atmosphere:

Numerics and fluid mechanics in Engineering,
Cloud microphysics & volcanic plumes in Geography,
Radiation belts and satellite data at BAS.

Now a Research Software Engineer (RSE) at the Institute of Computing for Climate Science (ICCS) working with various

This talk can be summarised as “things I wish I’d known sooner.”

What is Research Software?

Major Computational Programs

Data processing

Experiment support

Bathymetry by NOAA under public domain
CTD Bottles by WHOI under public domain
Keeling Curve by Scripps under public domain
Climate simulation by Los Alamos National Laboratory under CC BY-NC-ND
Dawn HPC by Joe Bishop with permission

Why does this matter?

Why does this matter?¹

def calc_p(n,t):
    return n*1.380649e-23*t
data = np.genfromtxt("mydata.csv")
p = calc_p(data[0,:],data[1,:]+273.15)
print(np.sum(p)/len(p))

What does this code do?

# Boltzmann Constant and 0 Kelvin
Kb = 1.380649e-23
T0 = 273.15

def calc_pres(n, t):
    """
    Calculate pressure using ideal gas law p = nkT

    Parameters:
        n : array of number densities of molecules [N m-3]
        t : array of temperatures in [K]
    Returns:
         array of pressures [Pa]
    """
    return n * Kb * t


# Read in data from file and convert T from [oC] to [K]
data = np.genfromtxt("mydata.csv")
n = data[0, :]
temp = data[1, :] + T0

# Calculate pressure, average, and print
pres = calc_pres(n, temp)
pres_av = np.sum(pres) / len(pres)
print(pres_av)

Virtual Environments

What?

A self-contained python environment
Packages installed in a local folder
Advised to use on a per-project basis

Why?

Avoid system pollution
Allow different versions
Reproducibility - set versions

Linux/macOS
Windows

$ python3 -m venv myvenv
$ source myvenv/bin/activate
(myvenv) $ pip install <packagename>
(myvenv) $ deactivate
$

PS> python -m venv myvenv
PS> source venv/bin/activate
(myvenv) PS> pip install <packagename>
(myvenv) PS> deactivate
PS>

For more information see the Real Python article.
For those using conda there are also environments, set up in a slightly different way.

Exercise 1

Scenario: you have just finished some simulations with a climate model that should improve precipitation modelling and have the output data as a netCDF file.

You know that your colleague has produced relevant figures and analysis before, so ask them for a copy of their code (yay, reuse :+1:).

Go to exercise 1 and:

Examine the code in precipitation_climatology.py
Set up a virtual environment
Install the necessary dependencies
Run the code - does it do what you thought?

Python PEPs

Python Enhancement Proposals

Technical documentation for the python community
Guidelines, standards, and best-practice

Relevant to us today are:

PEP8 - Python Style Guide (Rossum, Warsaw, and Coghlan 2001, 2013)
PEP257 - Docstring Conventions (Goodger and Rossum 2001)
PEP621 - Packaging (Cannon et al. 2020)

PEP8 and Formatting

PEP8 & Formatting

“Readability counts”
- Tim Peters in the Zen of Python

By ensuring code aligns with PEP8 we:

standardise style,
conform to best-practices, and
improve code readability to
make code easier to share, and
reduce misinterpretation.

“But I don’t have time to read and memorise all of this…”

PEP8 & Formatting - Black

Black (Langa 2020) - black.readthedocs.io

a PEP 8 compliant formatter
- Strict subset of PEP8
- “Opinionated so you don’t have to be.”
For full details see Black style
Try online

Linux/macOS
Windows

(myvenv) $ pip install black
(myvenv) $ black myfile.py
(myvenv) $ black mydirectory/

(myvenv) PS> pip install black
(myvenv) PS> black myfile.py
(myvenv) PS> black mydirectory/

PEP8 & Formatting - Black - Example

def long_func(x, param_one, param_two=[], param_three=24, param_four=None,
        param_five="Empty Report", param_six=123456):


    val = 12*16 +(24) -10*param_one +  param_six

    if x > 5:

        print("x is greater than 5")


    else:
        print("x is less than or equal to 5")


    if param_four:
        print(param_five)



    print('You have called long_func.')
    print("This function has several params.")

    param_2.append(x*val)
    return param_2

def long_func(
    x,
    param_one,
    param_two=[],
    param_three=24,
    param_four=None,
    param_five="Empty Report",
    param_six=123456,
):
    val = 12 * 16 + (24) - 10 * param_one + param_six

    if x > 5:
        print("x is greater than 5")

    else:
        print("x is less than or equal to 5")

    if param_four:
        print(param_five)

    print("You have called long_func.")
    print("This function has several params.")

    param_2.append(x * val)
    return param_2

PEP8 & Formatting - Black

I suggest incorporating into your projects now
- Well suited to incorporation into continuous integration of git hooks.
- Widely-used standard¹
A version for jupyter notebooks exists.

Exercise 2

Go to exercise 2 and:

install black
run black on precipitation_climatology.py
examine the output
- Is it more readable?
- Is there any aspect of the formatting style you find unintuitive?is it better?

PEP8 & Formatting - PyLint

Static Analysis

Check the code without running it
Catch issues before you run any code
Improve code quality¹

There are various tools available:

pycodestyle
flake8
Pylint
ruff

Linux/macOS
Windows

(myvenv) $ pip install pylint
(myvenv) $ pylint myfile.py
(myvenv) $ pylint mydirectory/

(myvenv) PS> pip install pylint
(myvenv) PS> pylint myfile.py
(myvenv) PS> pylint mydirectory/

PEP8 & Formatting - PyLint - Example

def long_func(
    x,
    param_one,
    param_two=[],
    param_three=24,
    param_four=None,
    param_five="Empty Report",
    param_six=123456,
):
    val = 12 * 16 + (24) - 10 * param_one + param_six

    if x > 5:
        print("x is greater than 5")

    else:
        print("x is less than or equal to 5")

    if param_four:
        print(param_five)

    print("You have called long_func.")
    print("This function has several params.")

    param_2.append(x * val)
    return param_2

(myvenv) $ pylint long_func.py
************* Module long_func
long_func.py:1:0: C0116: Missing function or method docstring (missing-function-docstring)
long_func.py:1:0: W0102: Dangerous default value [] as argument (dangerous-default-value)
long_func.py:1:0: R0913: Too many arguments (7/5) (too-many-arguments)
long_func.py:24:4: E0602: Undefined variable 'param_2' (undefined-variable)
long_func.py:25:11: E0602: Undefined variable 'param_2' (undefined-variable)
long_func.py:4:4: W0613: Unused argument 'param_two' (unused-argument)
long_func.py:5:4: W0613: Unused argument 'param_three' (unused-argument)

------------------------------------------------------------------
Your code has been rated at 0.00/10

(myvenv) $

PEP8 & Formatting - PyLint - Example

def long_func(
    x,
    param_one,
    param_two=[],
    param_four=None,
    param_five="Empty Report",
    param_six=123456,
):
    val = 12 * 16 + (24) - 10 * param_one + param_six

    if x > 5:
        print("x is greater than 5")

    else:
        print("x is less than or equal to 5")

    if param_four:
        print(param_five)

    print("You have called long_func.")
    print("This function has several params.")

    param_two.append(x * val)
    return param_two

(myvenv) $ pylint long_func.py
************* Module long_func
long_func.py:1:0: C0114: Missing module docstring (missing-module-docstring)
long_func.py:1:0: C0116: Missing function or method docstring (missing-function-docstring)
long_func.py:1:0: W0102: Dangerous default value [] as argument (dangerous-default-value)
long_func.py:1:0: R0913: Too many arguments (6/5) (too-many-arguments)

------------------------------------------------------------------
Your code has been rated at 6.36/10 (previous run: 0.00/10, +6.36)

(myvenv) $

Search the error code to understand the issue:

docs for W0102

IDE Integration

Catch issues before running PyLint
Gradually coerces you to become a better programmer
Available on all good text editors and emacs:
- Vim
- pycharm
- Sublime
- VSCode
- emacs

Exercise 3

Go to exercise 3 and:

install pylint
run pylint on precipitation_climatology.py
examine the report and try and address some of the issues.
- Ignore missing docstrings and f-strings for now - we’ll come to them later.
- Try and deal with: W0611 Unused imports, C0412 Ungrouped imports, W0102 Dangerous default
- If you feel like it you could try and fix: W0621 Redefining name, W1514 Unexplicit open
- Unless you are really keen don’t worry about: R0913 Too many arguments, C0103 Unconforming naming style.

Extensions:

try and add linting to your preferred text editor or IDE
explore the option to supress pylint warnings
explore the configuration options for pylint

Comments and Docstrings

Comments

Comments are tricky, and very much to taste.

Some thoughts:¹

“Programs must be written for people to read and […] machines to execute.”
- Hal Abelson

“A bad comment is worse than no comment at all.”

“A comment is a lie waiting to happen.”

=> Comments have to be maintained, just like the code, and there is no way to check them!

Cat code comment image by 35_equal_W

Comments to avoid

Dead code e.g.

# plt.plot(time, velocity, "r0")
plt.plot(time, velocity, "kx")
# plt.plot(time, acceleration, "kx")
# plt.ylabel("acceleration")
plt.ylabel("velocity")

Variable definitions e.g.
```
# Set Force
f = m * a
```
Redundant comments e.g. i += 1 # Increment i

Comments - some thoughts¹

Comments should not duplicate the code.
Good comments do not excuse unclear code.
- Comments should dispel confusion, not cause it.
- If you can’t write a clear comment, there may be a problem with the code.
Explain unidiomatic code in comments.
Provide links to:
- the original source of copied code.
- external references where they will be most helpful.
Use comments to mark incomplete implementations.
Comments are not documentation.
- Read by developers, documentation is for…

Docstrings

These are what make your code reusable (by you and others).

In python docstrings are designated at the start of ‘things’ using triple quotes: """...""".
PEP257 (Goodger and Rossum 2001) tells us what docstrings should say.
Specific conventions tell us how they should say it.
Where comments describe how it works, docstrings describe how to use it.
Unlike comments, docstrings follow a set format.

Various formatting options exist: numpy, Google, reST, etc.
We will use numpydoc it is readable and widely used in scientific code.
Full guidance for numpydoc is available.

Docstrings

Key components:

A description of what the thing is.
A description of any inputs (Parameters).
A description of any outputs (Returns).

Consider also:

Extended summary
Errors raised
Usage examples
Key references

"""
Short one-line description.

Parameters
----------
name : type
    description of parameter

Returns
-------
name : type
    description of return value
"""

Docstrings

Key components:

A description of what the thing is.
A description of any inputs (Parameters).
A description of any outputs (Returns).

def calculate_gyroradius(mass, v_perp, charge, B, gamma=None):
    """
    Calculates the gyroradius of a charged particle in a magnetic field

    Parameters
    ----------
    mass : float
        The mass of the particle [kg]
    v_perp : float
        velocity perpendicular to magnetic field [m/s]
    charge : float
        particle charge [coulombs]
    B : float
        Magnetic field strength [teslas]
    gamma : float, optional
        Lorentz factor for relativistic case. default=None for non-relativistic case.

    Returns
    -------
    r_g : float
        Gyroradius of particle [m]

    Notes
    -----
    .. [1]  Walt, M, "Introduction to Geomagnetically Trapped Radiation,"
       Cambridge Atmospheric and Space Science Series, equation (2.4), 2005.
    """

    r_g = mass * v_perp / (abs(charge) * B)

    if gamma:
        r_g = r_g * gamma

    return r_g

Docstrings - pydocstyle

pydocstyle is a tool we can use to help ensure the quality of our docstrings.¹

(myvenv) $ pip install pydocstyle
(myvenv) $ pydocstyle myfile.py
(myvenv) $ pydocstyle mydirectory/
(myvenv) $
(myvenv) $
(myvenv) $ pydocstyle gyroradius.py
gyroradius.py:2 in public function `calculate_gyroradius`:
        D202: No blank lines allowed after function docstring (found 1)
gyroradius.py:2 in public function `calculate_gyroradius`:
        D400: First line should end with a period (not 'd')
gyroradius.py:2 in public function `calculate_gyroradius`:
        D401: First line should be in imperative mood (perhaps 'Calculate', not 'Calculates')
(myvenv) $

Note: pydocstyle does not catch missing variables in docstrings. This can be done with Pylint’s docparams and docstyle extensions but is left as an exercise to the reader.

def calculate_gyroradius(mass, v_perp, charge, B, gamma=None):
    """
    Calculates the gyroradius of a charged particle in a magnetic field

    Parameters
    ----------
    mass : float
        The mass of the particle [kg]
    v_perp : float
        velocity perpendicular to magnetic field [m/s]
    charge : float
        particle charge [coulombs]
    B : float
        Magnetic field strength [teslas]
    gamma : float, optional
        Lorentz factor for relativistic case. default=None for non-relativistic case.

    Returns
    -------
    r_g : float
        Gyroradius of particle [m]

    Notes
    -----
    .. [1]  Walt, M, "Introduction to Geomagnetically Trapped Radiation,"
       Cambridge Atmospheric and Space Science Series, equation (2.4), 2005.
    """

    r_g = mass * v_perp / (abs(charge) * B)

    if gamma:
        r_g = r_g * gamma

    return r_g

Exercise 4

Go to exercise 4 and examine the comments:

Is there any dead code?
- How is it best to handle it?
Are comments used sensibly?
- Are any redundant and better off being removed?
- Is there anywhere that would benefit from a comment?

Docstrings:

Work through the file adding docstrings where they are missing.
If you are unsure about variable types or meanings at any point you can sneak a look ahead to the code in exercise 5.

Writing better (Python) code

f-strings

A better way to format strings since Python 3.6
Not catching on because of self-teaching from old code.

Strings are prepended with an f allowing variables to be used in-place:

name = "electron"
mass = 9.1093837015E-31

# modulo
print("The mass of an %s is %.3e kg." % (name, mass))

# format
print("The mass of an {} is {:.3e} kg.".format(name, mass))

# f-string
print(f"The mass of an {name} is {mass:.3e} kg.")

f-strings can take expressions:

print(f"a={a} and b={b}. Their product is {a * b}, sum is {a + b}, and a/b is {a / b}.")

See Real Python for more information.

Remove Magic Numbers

Numbers in code that are not immediately obvious.

Hard to read
Hard to maintain
Hard to adapt

Instead:

Name a variable conveying meaning
Set to a constant
Use a comment to explain

numberwang by Mitchell and Webb under fair use

Remove Magic Numbers

"""Module implementing pendulum equations."""
import numpy as np

def get_period(l):
    """..."""
    return 2.0 * np.pi * np.sqrt(l / 9.81)

def max_height(l, theta):
    """..."""
    return l * np.cos(theta)

def max_speed(l, theta):
    """..."""
    return np.sqrt(2.0 * 9.81 * max_height(l, theta))

def energy(m, l, theta):
    """..."""
    return m * 9.81 * max_height(l, theta)

def check_small_angle(theta):
    """..."""
    if theta <= np.pi / 1800.0:
        return True
    return False

def bpm(l):
    """..."""
    return 60.0 / get_period(l)

"""Module implementing pendulum equations."""
import numpy as np

GRAV = 9.81

def get_period(l):
    """..."""
    return 2.0 * np.pi * np.sqrt(l / GRAV)

def max_height(l, theta):
    """..."""
    return l * np.cos(theta)

def max_speed(l, theta):
    """..."""
    return np.sqrt(2.0 * GRAV * max_height(l, theta))

def energy(m, l, theta):
    """..."""
    return m * GRAV * max_height(l, theta)

def check_small_angle(theta, small_ang=np.pi/1800.0):
    """..."""
    if theta <= small_ang:
        return True
    return False

def bpm(l):
    """..."""
    # Divide 60 seconds by period [s] for beats per minute
    return 60.0 / get_period(l)

Put config in a config file

Ideally we shouldn’t have hop in and out of the code (and recompile in higher level langs) every time we change a runtime setting
No easy record of runs

Instead:

It’s easy to read a json file into python as a dictionary Handle as you wish - create a class, read to variables etc.
Could even make config filename a command line argument

{
  "config_name": "June 2022 m01 n19 run",
  "start_date": "2022-05-28 00:00:00",
  "end_date": "2022-06-12 23:59:59",
  "satellites": ["m01", "n19"],
  "noise_floor": [3.0, 3.0, 3.0],
  "check_SNR": true,
  "L_lim": [1.5, 8.0],
  "telescopes": [90],
  "n_bins": 27
}

import json


with open('config.json') as json_file:
    config = json.load(json_file)

print(config)

{'config_name': 'June 2022 m01 n19 run', 'start_date': '2022-05-28 00:00:00', 'end_date': '2022-06-12 23:59:59', 'satellites': ['m01', 'n19'], 'noise_floor': [3.0, 3.0, 3.0], 'check_SNR': True, 'L_lim': [1.5, 8.0], 'telescopes': [90], 'n_bins': 27}

Exercise 5

Magic Numbers

Look through the code and identify any magic numbers.
Implement what you feel is the best approach in each case

f-strings

Look for any string handling (currently using the .format() approach) and update it to use f-strings.
- Is the intent clearer?
- Is the layout of the data written to file easier to understand?

Configuration settings

There is helpfully a list of configurable inputs at the end of the file under "__main__".
We can improve on this, however, by placing them in a configuration file.
Create an appropriate json file to be read in as a dictionary and passed to the main function.

Other things

Beyond the scope of today are a few other honourable mentions:

Functions and modules
Packaging
- Breaking projects into modules and __init__.py
- Distributing projects with pyproject.toml
Documentation
- Auto-generation from docstrings with sphinx or mkdocs
Type hinting
- Adding type hinting to python code - how and why?
- Type checking with mypy

These lessons will be added to the course content in future but are beyond the scope of today.

Closing

Where can I get help?

BAS is developing a new Digital Innovation Team who can help with software engineering tasks and training:

Tasked with developing common digital infrastructure
Composed of four Research Software Engineers
Contact digitalinnovation@bas.ac.uk or James Byrne (jambyr) directly

The Technical Development Community (in Teams) can assist with general enquiries.
For all IT requests, please use the IT ServiceDesk

Look out for future training events including Software in Polar Science in February.

Where can I learn more?

References and links in these slides
Writing Clean Scientific Software Webinar (Murphy 2023)
Cambridge RSE Seminars
- Weekly presentations in West Cambridge
- rse.group.cam.ac.uk
RSE slack workspace

Get in touch:

Jack Atkinson

jackatkinson.net

jwa34[AT]cam.ac.uk

jatkinson1000

@jatkinson1000@fosstodon.org

References

The code in this workshop is based on a script from (Irving 2019).

Cannon, B, D Ingram, P Ganssle, P Gedam, S Eustace, T Kluyver, and T Chung. 2020. “PEP 621 – Storing project metadata in pyproject.toml.” https://peps.python.org/pep-0621/.

Goodger, D, and G van Rossum. 2001. “PEP 257 – Docstring Conventions.” https://peps.python.org/pep-0257/.

Irving, Damien. 2019. “Python for Atmosphere and Ocean Scientists.” Journal of Open Source Education 2 (16): 37. https://doi.org/10.21105/jose.00037.

Langa, Ł. 2020. “Black: The uncompromising Python code formatter.” https://github.com/psf/black. https://black.readthedocs.io/en/stable/.

Murphy, N. 2023. “Writing Clean Scientific Software.” In. Presented at the HPC Best Practices Webinar Series. https://www.youtube.com/watch?v=Q6Ksu_uX3bc.

Rossum, G van, B Warsaw, and A Coghlan. 2001, 2013. “PEP8 – Style Guide for Python Code.” https://peps.python.org/pep-0008/.

Spertus, E. 2021. “stackoverflow - Best practices for writing code comments.” https://stackoverflow.blog/2021/12/23/best-practices-for-writing-code-comments/.

ICCS ReproHack

March 12th 2024
Climate science reproducibility hackathon
reprohack.org/event/27
Fully online

Come and learn more about software reproducibility by trying to reproduce results from papers. No advanced programming skills needed, you will work in teams and won’t do actual coding, just trying to get submitted codes to run (with our support).
If you would like some friendly feedback on your own code’s reproducibility, please submit a paper.

Powering up python

Precursors

Slides and Materials

Licensing

Precursors

whoami

What is Research Software?

Why does this matter?

Why does this matter?1

Virtual Environments

Virtual Environments

What?

Why?

Exercise 1

Python PEPs

PEP8 and Formatting

PEP8 & Formatting

PEP8 & Formatting - Black

PEP8 & Formatting - Black - Example

PEP8 & Formatting - Black

Exercise 2

PEP8 & Formatting - PyLint

PEP8 & Formatting - PyLint - Example

PEP8 & Formatting - PyLint - Example

IDE Integration

Exercise 3

Comments and Docstrings

Comments

Comments to avoid

Comments - some thoughts1

Docstrings

Docstrings

Docstrings

Docstrings - pydocstyle

Exercise 4

Writing better (Python) code

f-strings

Remove Magic Numbers

Remove Magic Numbers

Put config in a config file

Exercise 5

Other things

Closing

Where can I get help?

Where can I learn more?

References

ICCS ReproHack

Why does this matter?¹

Comments - some thoughts¹
